Core V1 Core V1 Core V1 Core V1 Core V1 Core V1
Core V1

Core V1

In stock
型号
CA-1B8-00S1WN-00
USD$ 49.99

P/N: CA-1B8-00S1WN-00
-游戏风格-Mini机箱





曜越Core V1迷你型机箱

曜越Core V1迷你型机箱支持ITX主机板,前置200mm超大风扇,轻巧外型搭配极致化效能设计,可打造理想水冷或气冷最大化。另外,四面可置换式的侧板设计,可依喜好调整面板位置,让玩家在有限的空间内,同时打造专属自己的理想超频世界!

Core V1 Video

井然有序 分层管理

机箱内部提供最佳结构设计,上层具备足够的空间可让风流顺畅,除了提升散热效能也方便打造个人专属的美学设计;下层则可放置电源供应器和提供方便的理线管理。另外客制化2.5吋和3.5吋硬盘插槽,可依玩家需求交换3.5吋硬盘持架位置,并且能移除2.5吋与3.5吋硬盘槽,来换取最大的内部机箱空间,提升水冷或者气冷散热效能。

极致散热效能

前置200mm超大静音风扇,及后方预留两组80mm风扇安装空间,支援所有散热系统,展现极致优异散热效能。





可置换式侧板设计

四面可置换式侧板设计,可依玩家喜好调整不同面板的位置,内部空间一览无遗。并在机箱底部附上可拆式防尘网及防震橡胶软垫。



贴心设计I/O界面

前置超高速双USB3.0传输埠,并搭配HD高音质耳机音效孔,为使用者带来更方便快捷的高质量体验。



理想扩充性



Core V1机箱内部灵巧设计,拥有高度储存扩充性。可安装四颗硬盘和长达260mm的高阶显卡;另外内部空间可容纳长140mm塔式散热器以及长180mm高阶电源供应器,并仍留有80mm的理线空间;而模块化硬盘插槽设计,容易组装、方便扩充,可为高阶游戏玩家提供最佳的散热解决方案。




散热排兼容列表

散熱排相容列表
  120mm 140mm
正前方 * *
後方

Water 3.0 Series
  Performer Pro
正前方 * *
後方




风扇兼容列表



風扇相容列表



80mm

120mm

140mm

200mm

正前方

-

1

1

1

後方

2

-

-

-

Thermaltake 相容風扇

Pure風扇系列



*

*

*

Luna 風扇系列



*

*

*

Odin風扇系列



*









More Information
型号 CA-1B8-00S1WN-00
系列 Core 系列
机种 Core V1
机型 Mini Case
尺寸(高*宽*深) 276 x 260 x 316 mm
(10.9 x 10.2 x 12.4 inch)
侧窗 Transparent Window (Interchangeable)
颜色 Exterior & Interior : Black
材质 SPCC
散热系统 Front (intake) :
200 x 200 x 30 mm fan (800rpm, 13dBA)
PCI插槽 2
适用主机板 6.7” x 6.7” (Mini ITX)
I/ O连接埠 USB 3.0 x 2, HD Audio x 1
电源供应器 Standard PS2 PSU (optional)
风扇支持 Front:
1 x 120mm or
1 x 140mm or
1 x 200mm
Rear:
2 x 80mm
水冷排支援 Front:
1 x 120mm or
1 x 140mm
Clearance CPU cooler height limitation: 140mm
VGA length limitation:
255mm (Inner chassis)
285mm (Outer chassis)
PSU length limitation: 200mm
[H]ard|OCP
2018-12-07

The Thermaltake Core V1 should be at the top of the list for anyone building a LAN box, HTPC, or Steam Machine. The ability to pack this case with full-size, high-end hardware will make it a favorite with enthusiasts looking to reduce their system's footprint without sacrificing performance.

<More>
Tweak Town
2018-12-07

Just as the Prodigy did years ago, I can see the Core V1 becoming the basis for many mods to come. It is also one of those cases that will make you ponder buying all the rest of the Mini-ITX gear just so you can complete a build in, and have one of these Core V1 Mini-ITX cases gracing your desk. That alone says volumes about a design. Thermaltake has won us over once again by showing they can offer unique, and stunning designs, even when it comes to a Small Form Factor chassis.

<More>
The Mod Zoo
2018-12-07

This case has so many capabilities. It’s very easy to disassemble and install all of your computer components. This was such a stress free assembly. There is plenty of room for cable management. Mostly everything that can fit in a larger case can fit in this one from the full size power supply, it can house a 140mm cpu tower cooler, a full size (2 expansion slot sized) GPU of up to 255mm, it can hold 4 solid state drives, and has water cooling capabilities up to a 140mm aio cpu cooler or radiator.

<More>
MYC (Mod Your Case)
2018-12-07

 Pro

  • Design
  • Auch im Innenraum lackiert
  • Kühlmöglichkeiten
  • Moddingpotential



<More>
Proclockers
2018-12-07

"The Thermaltake Core V1 is a very nice addition to the Mini-ITX world, and would do very well in any living room or dorm"

Likes

  • Solid construction
  • Good looks
  • Interchangeable panels
  • Great ventilation
  • Support for AIO liquid cooling
  • Easy to build in



<More>
Play3r
2018-12-07

"The design of the Core V1 is probably its strongest point and shines above other M-ITX cases I have previously seen.  The support for full size graphics cards given and the little cubby hole sized gap which allows the graphics card to go into the front panel is a particular highlight..."

Pros:

- Compact M-ITX chassis
- Great support for graphics cards
- Supports coolers up to 140mm in height
- Bargain price



<More>
Game IT
2018-12-07

Pro:

  • Robustez y calidad de materiales
  • Sumamente compacta
  • Distribución eficiente del espacio
  • Buena refrigeración
  • Puede albergar tarjetas gráficas de gran tamaño
  • USB 3.0
<More>
Inside Hardware
2018-12-07

 Pro:

- Ottimo rapporto Qualità/Prezzo
- Dimensioni molto compatte
- Pannelli intercambiabili
- Ampio spazio interno in rapporto alle dimensioni
- Facilità di installazione
- Buona Robustezza e qualità costruttiva
- Buone performance di raffreddamento



<More>
Game Zoom
2018-12-07

Pro

  • sehr saubere Verarbeitung
  • erleichterter Hardwareeinbau
  • sehr gute Kühlung
  • 1x 200mm Lüfter integriert
  • Sichtfenster
  • sehr leise
  • USB 3.0 intern
  • Staubfilter
  • passendes Gewicht
  • hübsche Optik
  • günstiger Preis
<More>
VR World
2018-12-07

EDITOR'S RATING

Excellent build quality, easy to access, and a great price. The Silver Award and Innovation Award were given

<More>
Hexagon PC
2018-12-07

"So, out of all of the mini-ITX cases I’ve used, owned and built into over the past year, this has gotto be one of my absolute favorites. It’s quite up there with the 250D and the nCase M1. I should get on that nCase review by the way. With its maximum portability and efficient usage of its internal space coupled with its price point, this case is a definite must buy for anyone coming into mini-ITX..."

<More>
Pure OC
2018-12-07

BOTTOM LINE:
If I had to describe the Core V1 in a few words it would have to be "Functional", "Ease" and "Personal". At this particular moment Thermaltake is hitting pretty close to the bulls-eye.

<More>
Think Computers
2018-12-07

"I honestly cannot say a single bad thing about this case. If you are looking for a Mini-ITX case this should be your first choice. Currently the Core V1 is selling at my favorite online retailer for $44.90, which is a price that you cannot complain about either. Overall ThinkComputers gives the Thermaltake Core V1 Mini-ITX Case a 10 out of 10 score and our Editor’s Choice Award."

Pros:

– Room inside for 140 mm CPU Coolers
– Room inside for 285 mm graphic cards
– Fits full-size power supplies
– All panels can be removed and are interchangeable
– 200 mm fan included, plus room for expansion



<More>
eTeknix
2018-12-07

“This is without a doubt one of the best mini-ITX chassis on the market. It’s smaller, more capable and cheaper than almost everything else in its class, with the added bonus that it’s flexible, very well made and extremely easy to work with. If you’re in need of a compact gaming rig, this should be right at the top of your shopping list.”

Pros

  • Modular design
  • Excellent build quality
  • Room for high-end components
  • Water cooling support
  • Lots of air flow
  • Budget friendly
  • Easy to work with
  • Compact size



<More>
KitGuru
2018-12-07

 KitGuru says: An impressive case from Thermaltake and at the modest asking price, difficult to ignore.

Pros

  • Understated design.
  • Compact form factor
  • Good value for money.
  • Quiet operation.



<More>
Tweak.dk
2018-12-07

 Godt:

  • Nem adgang til hardwaren
  • Nem montage
  • Alle sider passer hele vejen rundt, så man kan flytte vinduet rundt

Score: 9 + Safe Buy award

<More>
Hardware Upgade
2018-12-07

Thermaltake Core V1 può essere un'ottima soluzione per chi ha bisogno di posizionare il proprio sistema desktop sulla scrivania e non vuole sacrificare troppo spazio, sia sul piano di lavoro che verticalmente. Ma è anche per l'utente che necessita di un sistema potente e senza troppi compromessi, grazie alle buone doti di raffreddamento, alla possibilità di alloggiare un alimentatore di dimensioni standard e di installare una scheda video dedicata anche di dimensioni parecchio generose.

<More>
NikkTech
2018-12-07

 PROS

- Build Quality
- Size
- Interchangeable Panels
- 200mm Fan Preinstalled
- Room For Up To 4 Drives
- Spacious Interior (260mm Long GPUs/200mm Long PSUs/160mm Tall CPU Coolers)
- Adjustable Mainboard Tray Position
- Price (For Some)

<More>
Mr Apvel
2018-12-07

Pro

  • Sturdy
  • Easy to build with
  • Most cables sleeved
  • Anti-vibration pads for HDDs

<More>
Overclockers
2018-12-07

Thermaltake Core V1 — это отличный маленький корпус, основными достоинствами которого есть продуманная конструкция, хорошая вентиляция, удобство сборки и обслуживания, компактные габариты и простой внешний вид. Материнская плата формата Mini-ITX — является единственным нестандартным элементом в данном шасси, в то время как кулер, видеокарта, блок питания и накопители подойдут и обычного размера. Это одно из немногих шасси, которые позволяют собрать подобную конфигурацию в столь небольшом объеме без особых сложностей и необходимости с линейкой вымерять все компоненты на предмет совместимости.

я без колебаний могу назвать Thermaltake Core V1 одним из лучших вариантов реализации концепции Mini-ITX-корпуса, которые когда-либо попадали в мои руки.



<More>
Citilink
2018-12-07

Плюсы

  • Возможность менять местами стенки корпуса
  • Возможность установки СВО
  • Большой 200 мм вентилятор в комплекте
  • Стильный дизайн



<More>
